41 / 56
CENTURION-R 2014
41
SUGGESTED RETAIL PRICE IN PLN
net
[incl VAT]
NICE
NON-REBATED
DOOR LEAVES
499,00
(613,77)
PRICE OF THE DOOR LEAF FROM:
S
Fig.
Pocket forged in the wall for hinge
Hm
200
200
1240
200
Sm
Pocket forged in the wall
– max. 20 mm
Pocket forged in the wall
– max. 20 mm
DIMENSIONS OF ADJUSTABLE DOOR FRAME FOR
NON REBATED DOORS O/SB
DIMENSIONS OF THE DOOR FRAME
DIMENSIONS 60 70 80 90 100
Sm
684 784 884 984 1084
S
615 715 815 915 1015
Hm
2060
S - width of the door leaf
Sm - suggested width of the wall opening
Hm - suggested height of the door opening
LEGEND FOR THE DRAWING
CUTAWAY OF THE DOOR FRAME FOR NON REBATED DOORS (O/SB)
46
16
R
ADJUSTMENT RANGE
80
22
46
16
80
22
22
22
R
46
16
R
ADJUSTMENT RANGE
80
22
22
Type of the
door frame
wall
thickness (R)
PRICE (PLN)
NET
[INCL VAT]
B
95-115
499,00
[613,77]
C 120-140
499,00
[613,77]
D 140-160
529,00
[650,67]
E
160-180
529,00
[650,67]
F
180-200
559,00
[687,57]
G 200-220
559,00
[687,57]
H 220-240
599,00
[736,77]
Type of the
door frame
wall
thickness (R)
PANELS
ASSEMBLAGE
PRICE (PLN)
NET
[INCL VAT]
I
240-260 140+100
599,00
[736,77]
J
260-280 140+120
599,00
[736,77]
K
280-300 140+140
599,00
[736,77]
1
300-320 140+160
629,00
[773,67]
2
320-340 140+180
659,00
[810,57]
3
340-360 140+200
689,00
[847,47]
4
360-380 140+220
719,00
[884,37]
5
380-400 220+160
749,00
[921,27]
6
400-420 220+180
779,00
[958,17]
7
420-440 220+200
809,00
[995,07]
8
440-460 220+220
839,00
[1031,97]
Type of the
door frame
wall
thickness (R)
PANELS
ASSEMBLAGE
PRICE (PLN)
NET
[INCL VAT]
9
460-480 220+120+120
869,00
[1068,87]
0
480-500 220+140+120
899,00
[1105,77]
NEW!
