CENTURION-R 2014

39

FOGO

FIREPROOF DOUBLE DOOR

BLOCK WOODEN DOOR FRAME FOR FOGO DOUBLE DOOR

BLOCK WOODEN DOOR FRAME FOR FOGO SINGLE DOOR

DIMENSION

DOOR FRAME

70

80

90

Sz

812 912 1012

DIMENSION

DOOR FRAME

70

80

90

So

704 804 904

DIMENSION

DOOR FRAME

70

80

90

Sm 842 942 1042

DIMENSION

DOOR FRAME

70

80

90

Sw 728 828 928

All sizes in mm.

5

Passive

door leaf (B)

Upper Bolt

Second lock

(upper)

Main lock

3-plane adjustable hinges

(EI

2

30)

3-plane adjustable

hinges (EI

2

30)

3-plane adjustable hinges

(EI

2

30)

Second Lock

strike plate

Main lock

strike plate

Lower bolt

0

54

54

Hardwood

doorstep

Sz

248

450

920

72

55

538

1480

2070

B

A

So

Sw

S

Active

door leaf (A)

Second lock

Main lock

drop-down threshold

seal (gasket) for sound

- and smokeproof variant

Sz

100

100

1480

521

300

248

Suggested dimension of the wall opening height Hm=2085mm

Door frame opening height Ho=2016mm

Door frame opening height at rebated side Hw=2028mm

Total external door frame height Hz=2070mm

Sz

54

240

538

1480

Sw

So

So

Sw

0

Sm

Second lock

strike plate

Main lock

strike plate

Suggested door frame height Hm=2085mm

Height of the door frame opening Ho=2016mm

Height of the door frame opening at rebated side Hw=2028mm

Total external door frame height Hz=2070mm

Sz

54

240

538

1480

882

97

170

420

Sw

So

So

Sw

0

100

54

54

Sm
