of a Sa/Sm class (protective barrier against the propa-

gation of smoke and carbon oxide) and with acoustic

isolation rating Rw=32dB. Model is offered as a set with

wooden door frame.

CENTURION-R 2014

36

SUGGESTED RETAIL PRICE IN PLN

net

[incl VAT]

FOGO

In the glazed models - fire resistant transparent glass.

Model available in STANDARD technology. Block wo-

oden door frame 100x54 mm, veneered in same décor

as door leaf.

The door filling is made from fire rated particle board

• cylinder lock with higher thermal resistance (Y)

• three 3D hinges

• installation kit

• lock striking plate

• in the glazed models - fire resistant transparent glass

• seals with increased thermal resistance

• intumescent seal in the groove on the rebated side of

the door frame (version F1)

• intumescent“twin fin”seal against fire and smoke

in the groove on the rebated side of the door frame

(version F2)

• drop-down threshold seal at the bottom of

the door leaf (barrier against smoke, dirt and insects –

version F2)

• block wooden door frame 100x54mm

• cylinder lock with higher thermal resistance (Y)

• four 3D hinges

• installation kit

• lock striking plate

• in the glazed models - fire resistant transparent glass

• seals with increased thermal resistance

• intumescent seal in the groove on the rebated side of

the door frame (version F3)

• intumescent“twin fin”seal against fire and smoke

in the groove on the rebated side of the door frame

(version F4)

• drop-down threshold seal at the bottom of

the door leaf (barrier against smoke, dirt and insects –

version F4)

• block wooden door frame 100x54mm

CONSTRUCTION

AVAILABLE AT SURCHARGE

INCLUDED IN THE PRICE - VERSION 1 (F1,F2)

INCLUDED IN THE PRICE - VERSION 2 (F3, F4)

OPTION

PRICE (PLN)

NET

[INCL VAT]

second cylinder lock (P) and lock striking plate

35,00

[43,05]

security (anti-burglar) bolts (B)

65,00

[79,95]

Viewfinder (W)

75,00

[92,25]

Door closer

230,00

[282,90]

OPTION

PRICE (PLN)

NET

[INCL VAT]

Doorstep

30,00

[36,90]

Size 100

200,00

[246,00]

Size 110

300,00

[369,00]

Size 120

400,00

[492,00]

F1/F*, F2/F*

F1/P, F2/P

F1/S, F2/S

F1/M, F2/M

F3/F*, F4/F*

F3/P, F4/P

F3/S, F4/S

F3/M, F4/M

80, 90

70, 80, 90, 100, 110 70, 80, 90, 100, 110 70, 80, 90, 100, 110

80, 90

70, 80, 90, 100, 110 70, 80, 90, 100, 110 70, 80, 90, 100, 110

VERSION F1

VERSION F3

1195,00

[1469,85]

995,00

[1223,85]

1995,00

[2453,85]

1595,00

[1961,85]

2300,00

[2829,00]

2100,00

[2583,00]

3100,00

[3813,00]

2850,00

[3505,50]

VERSION F2

VERSION F4

1730,00

[2127,90]

1530,00

[1881,90]

2530,00

[3111,90]

2080,00

[2558,40]

2900,00

[3567,00]

2700,00

[3321,00]

3700,00

[4551,00]

3450,00

[4243,50]

*exclusively in DARK, ALDER, PEAR, NUSS decors

double doors in sizes 120, 130, 140, 150, 160, 170, 180 consisting of two standard single doors

TECHNOLOGY

PRODUCTS INSELECTEDDECORS

ARECOVEREDWITH6YEARSWARRANTY

DETAILSATTHEPOINTOFSALE

WARRANTY

see page 2 for details

1. In order to meet Technical Approval requirement the door closer must be installed (complying with PN-EN 1154:1994/A1:2004 norm).

2. FOGOmodel is always offered as a set with the door frame. Height correction not applicable.

3. In order to meet Technical Approval requirement for smoke proof doors a doorstep along with drop down seal is necessary.

4. Only use pin tumbler locks that comply with PN-EN 1303:2007/AC:2008 norm.

5. Suggested size of asymmetric pin tumbler lock for for EI

2

30 models – 30/45.

6. Suggested size of asymmetric pin tumbler lock for for EI

2

60 models – 30/45.

ADDITIONAL

INFORMATION

info!

Technical Approval: AT-15-6103/2013 ITB Warsaw [EI30, EI60]

Hygienic Atest: HK/B/0750/01/2012 PZH Warsaw [EI30, EI60]

VERSION

F3

EI

2

60

60 MINUTES

FIREPROOF

VERSION

F4

EI

2

60

60 MINUTES FIREPROOF

SMOKEPROOF SA/SM 60

SOUNDPROOF RW=32DB

VERSION

F1

EI

2

30

30 MINUTES

FIREPROOF

VERSION

F2

EI

2

30

30 MINUTES FIREPROOF

SMOKEPROOF SA/SM 30

SOUNDPROOF RW=32DB

PRICE OF FOGO DOUBLE DOOR = 2X PRICE OF FOGO SINGLE DOOR

to which the wooden lath is attached from three sides.

Outer layer is a flush (veneered or lacquered) or milled

veneered HDF board. In the glazed models fireproof

transparent glass is used. Model is available in STAN-

DARD technology. Wooden door frame with 100x54

profile, finished with décor.

Fogo model is designed for use as internal entry door

for private, public or multi-dwelling houses and offices.

We are offering two different models with special tech-

nical parametres - fire rating EI 30 (barrier preventing

the fire from spreading for 30 minutes), smokeproof

• FIREPROOF EI

2

30

EI 30

3

CLASS

S 30 32dB

• FIREPROOF EI

2

60

EI 60

3

CLASS

S 60 32dB

995,00

(1223,85)

PRICE

FROM:

PRICE OF THE DOOR SET (DOOR LEAF+BLOCK DOOR FRAME 100x54MM) FROM:
