CENTURION-R 2014
43
SLIDING DOOR SYSTEMS
brush anti-dust seal
hook lock
oval door pull
thimble
EXAMPLE OF INSTALLATION OF THE WALL-MOUNTED SLIDING DOOR
SYSTEM DIRECTLY TO THE WALL
HORIZONTAL CROSS-SELECTION OF THE WALL-MOUNTED
SLIDING DOOR SYSTEMMOUNTED DIRECTLY TO THE WALL
WALL-MOUNTED SYSTEM
DOOR LEAF DIMENSIONS
EXAMPLE OF INSTALLATION OF THE WALL-MOUNTED SLIDING DOOR SYSTEMWITH TUNNEL
HORIZONTAL CROSS-SELECTION OF THE WALL-MOUNTED SLIDING DOOR SYSTEMWITH TUNNEL
Only adjustable SW-type door frame is offered as doorway cover (tunnel) for wall-mounted sliding door system
(no groove and no seal)
90
101,5
2030
2018
2040
2050
2109
8
10
10
44
A
E
D
C
B
60
40
MW
SINGLE SLIDING SYSTEM
door leaf width
(mm)
sliding door gear
cover Mw (mm)
trolley track
length (mm)
644
1380
1800
744
1580
1800
844
1780
1800
944
1980
2000
SINGLE DOOR SLIDING SYSTEM
60
70
80
90
A
644
744
844
944
B
745
845
945
1045
C
667
767
867
967
D
647
747
847
947
E
603
703
803
903
101,5
2030
8
90
2109
max 2035
groove for the
floor-fixed guide
floor level
40
16,5
7
15
8
(does not apply to models: BOSTON ST+, DAKAR DP/P, INTRO,
AKUSTIK, FOGO, MODESTO).
44
A
E
60
40
13,8
All sizes in mm.
Fig.1
Pocket sliding door system (detail view)
bumper
beam
bumper
beam
tunnel
tunnel
wall
tunnel
sliding door
gear cover
spacers
sliding door
leaf
sliding door gear cover
wall
wall
wall
bumper
beam
bumper
beam
sliding door
gear cover
spacers
sliding door
leaf
wall
wall
sliding door leaf
sliding door leaf
