CENTURION-R 2014
26
SUGGESTED RETAIL PRICE IN PLN
net
[incl VAT]
KOBE
Inner structure consists of rail and stile with honeycomb
stabilizer filling (X-mash) – KO series, or particle board
filling – KW series. Outer layer is an HDF board finished
with two-way décor on both sides of the door. Apertu-
res filled with glass or milled panes finished with same
décor. Model is available in STANDARD technology.
Available in sizes 60, 70, 80, 90 and double doors (see
page 50).
*Door leaves finished in two-way decors (Cognac, Ginger,
Nut, Vog) can be manufactured in size 60 based on two-
-way decor size 70. This means that width correction is
being made by bilateral symmetric reduction of the width.
Part of the horizontal grain pattern does not change, whi-
le width of both of the vertical grain patterns is cut down.
Another possibility is to use same decor with one-way grain
pattern with vertical grain arrangement. Sizes 100, 110 are
made exclusively using one-way grain pattern décor.
• 4 variants of the lock available: lever tumbler lock (T),
bathroom lock (L)
cylinder lock (Y)
and economy lock (G)
• three pintle hinges
• in the glazed variants – white matt toughened safety
glass LAKMAT (I) or white ornamental shutter glass (H)
• option of correction of the door height by undercut
from the bottom up to 60mm
CONSTRUCTION
INCLUDED IN THE PRICE
COLORS
DOOR FRAMES INFORMATION: SEE PAGE 48
AVAILABLE AT SURCHARGE
OPTION
PRICE (PLN)
NET
[INCL VAT]
Ventilation holes + bushings (one row)
15,00
[18,45]
Ventilation grid
25,00
[30,75]
Ventilation undercut
25,00
[30,75]
Hinge covers (set per hinge)
4,00
[4,92]
Additional stile at the bottom of the door allowing for door height correction for up to 80mm
25,00
[30,75]
Inner filling with particle board
95,00
[116,85]
3D hinge (1set – 3 upper and lower elements – see page 54 for details)
30,00
[36,90]
Door leaf height correction at the factory (up to 60mm)
50,00
[61,50]
Door frame height correction at the factory (up to 60mm)
50,00
[61,50]
PRICE OF SINGLE DOOR SET = PRICES OF THE DOOR LEAF + DOOR FRAME
PRICE OF THE DOUBLE DOOR SET = PRICE OF THE DOOR LEAF x2 + PRICE OF THE DOOR FRAME x1.5
STANDARDTECHNOLOGY
KO/P
KO/L
KO/D
414,00
[509,22]
420,00
[516,60]
430,00
[528,90]
KO/R
KO/S
425,00
[522,75]
Nut
(NJ)
Cognac
(KJ)
Ginger
(IJ)
Vog
(VJ)
414,00
(509,22)
PRICE OF THE DOOR LEAF FROM:
For double door optional sidelight in size 40: pages 50-51
Sliding doors: see pages 42-43
