24 / 56
CENTURION-R 2014
24
SUGGESTED RETAIL PRICE IN PLN
net
[incl VAT]
SOFIA
CONSTRUCTION
INCLUDED IN THE PRICE
TABLE OF SURCHARGE OPTIONS FOR SOFIA MODEL
DOOR FRAMES INFORMATION: SEE PAGE 48
PRICE OF SINGLE DOOR SET = PRICES OF THE DOOR LEAF + DOOR FRAME
PRICE OF THE DOUBLE DOOR SET = PRICE OF THE DOOR LEAF x2 + PRICE OF THE DOOR FRAME x1.5
155,00
[190,65]
175,00
[215,25]
198,00
[243,54]
275,00
[338,25]
GROUP A
GROUP B
GROUP C
GROUP D
SF/P
Inner structure consists of rail and stile with honeycomb
stabilizer filling (X-mash) – SF series or particle board – SI
series. Outer layer is an HDF board finished with high-
-quality décor on both sides of the door. Model is availa-
ble in STANDARD technology (with the exception of SF
series in LATTE, MAGNOLIA, GRAPHITE, ACACIA, WHITE
(BA) which are available in SOFT technology). Available
in sizes 60*, 70, 80, 90 and double doors (see page 50).
*Door leaves finished in two-way decors (Cognac, Ginger,
Nut, Vog) can be manufactured in size 60 based on two-
-way decor size 70. This means that width correction is
being made by bilateral symmetric reduction of the width.
Part of the horizontal grain pattern does not change, whi-
le width of both of the vertical grain patterns is cut down.
Another possibility is to use same decor with one-way grain
pattern with vertical grain arrangement. Sizes 100, 110 are
made exclusively using one-way grain pattern décor.
• 4 variants of the lock available: lever tumbler lock (T),
bathroom lock (L)
cylinder lock (Y)
and economy lock (G)
• three pintle hinges
• option of correction of the door height by undercut
from the bottom up to 60mm
AVAILABLE AT SURCHARGE
OPTION
PRICE (PLN)
NET
[INCL VAT]
Ventilation holes + bushings (one row)
15,00
[18,45]
Ventilation grid
25,00
[30,75]
Ventilation undercut
25,00
[30,75]
Hinge covers (set per hinge)
4,00
[4,92]
Additional stile at the bottom of the door allowing for door height correction for up to 80mm
– STANDARD technology only
25,00
[30,75]
Sliding door version (see page 42-43)
25,00
[30,75]
Size 100, 110 with aperture and glass as in size 90, in STANDARD technology*
40,00
[49,20]
Inner filling with particle board (sizes 60-90), in STANDARD technology
95,00
[116,85]
Inner filling with particle board (size 100), in STANDARD technology
115,00
[141,45]
Inner filling with particle board (size 110), in STANDARD technology
135,00
[166,05]
3D hinge (1set – 3 upper and lower elements – see page 54 for details)
30,00
[36,90]
Door leaf height correction at the factory (up to 60mm)
50,00
[61,50]
Door frame height correction at the factory (up to 60mm)
50,00
[61,50]
Upper edge reinforcement for door closer
25,00
[30,75]
RAL, NCS COLORS ACCORDING TO THE COLOR GROUPS (SEE PAGE 52)
MODEL
GROUP 1
bright colors
GROUP 2
intermediate colors
GROUP 3
light colors
GROUP 4
dark colors
SOFIA
Surcharge for price group A
175,00
[215,25]
225,00
[276,75]
285,00
[350,55]
335,00
[412,05]
Door frames ready for
lacquering (p 48-49)
+40%
+50%
RAL COLOURS
PRICE (PLN)
NET
[INCL VAT]
Sliding door gear cover
50,00
[61,50]
Beam
10,00
[12,30]
Architraves and quarter-rounds
20,00
[24,60]
RAL and NCS colours
(excluding metallized ones)
Surcharges according to the table with colors (page 52), m.o.q. – 2ea
RAL
NCS
155,00
(190,65)
PRICE OF THE DOOR LEAF FROM:
For double door optional sidelight in size 40: pages 50-51
Sliding doors: see pages 42-43
PRODUCTS INSELECTEDDECORS
ARECOVEREDWITH6YEARSWARRANTY
DETAILSATTHEPOINTOFSALE
WARRANTY
seepage2 fordetails
