14 / 56
CENTURION-R 2014
14
SUGGESTED RETAIL PRICE IN PLN
net
[incl VAT]
RENO
Inner structure consists of rail and stile with honeycomb
stabilizer filling (X-mash)*. Outer layer is an HDF board
finished with high-quality décor on both sides of the
door. Aperture frame made from MDF with matching
décor. Model is available in SOFT technology (RX series)
and in STANDARD technology (RE series). Available in
sizes 60*, 70, 80, 90 and double doors (see page 50).
*Door leaves finished in two-way decors (Cognac, Ginger,
Nut, Vog) can be manufactured in size 60 based on two-
-way decor size 70. This means that width correction is
being made by bilateral symmetric reduction of the width.
Part of the horizontal grain pattern does not change, whi-
le width of both of the vertical grain patterns is cut down.
Another possibility is to use same decor with one-way grain
pattern with vertical grain arrangement. Sizes 100, 110 are
made exclusively using one-way grain pattern décor.
• 4 variants of the lock available: lever tumbler lock (T),
bathroom lock (L)
cylinder lock (Y)
and economy lock (G)
• three pintle hinges
• In the glazed variants – white matt toughened safety
glass LAKMAT
• option of correction of the door height by undercut
from the bottom up to 60mm
CONSTRUCTION
INCLUDED IN THE PRICE
COLORS
DOOR FRAMES INFORMATION: SEE PAGE 48
AVAILABLE AT SURCHARGE
OPTION
PRICE (PLN)
NET
[INCL VAT]
Ventilation holes + bushings (one row)
15,00
[18,45]
Ventilation grid (not available for sizes 60 and 70)
25,00
[30,75]
Ventilation undercut
25,00
[30,75]
Hinge covers (set per hinge)
4,00
[4,92]
Sliding door version (see page 42-43)
25,00
[30,75]
Additional stile at the bottom of the door allowing for door height correction for up to 80mm
- STANDARD TECHNOLOGY only
25,00
[30,75]
Size 100, 110, with aperture and glass as in size 90,
in STANDARD technology
40,00
[49,20]
Inner filling with particle board (sizes 60-90), in STANDARD technology
95,00
[116,85]
Inner filling with particle board (size 100), in STANDARD technology
115,00
[141,45]
Inner filling with particle board (size 110), in STANDARD technology
135,00
[166,05]
3D hinge (1set – 3 upper and lower elements – see page 54 for details)
30,00
[36,90]
Door leaf height correction at the factory (up to 60mm)
50,00
[61,50]
Door frame height correction at the factory (up to 60mm)
50,00
[61,50]
PRICE OF SINGLE DOOR SET = PRICES OF THE DOOR LEAF + DOOR FRAME
PRICE OF THE DOUBLE DOOR SET = PRICE OF THE DOOR LEAF x2 + PRICE OF THE DOOR FRAME x1.5
SOFTTECHNOLOGY -RX
STANDARDTECHNOLOGY -RE
GROUPA
GROUPC
GROUPB
Venge
(WR)
Ofram
(OR)
Acacia
(AK)
Chestnut
(KR)
Graphite
(GM)
Latte
(LM)
Magnolia
(MM)
Nut
(NJ)
Cognac
(KJ)
Ginger
(IJ)
Vog
(VJ)
GROUP A
GROUP A
GROUP B
GROUP B
GROUP C
GROUP C
RX/S, RE/S
RX/M, RE/M RX/D, RE/D
380,00
[467,40]
455,00
[559,65]
385,00
[473,55 ]
RX/P, RE/P
RX/L, RE/L
RX/R, RE/R
380,00
[467,40]
455,00
[559,65]
385,00
[473,55 ]
380,00
(467,40)
PRICE OF THE DOOR LEAF FROM:
For double door optional sidelight in size 40: pages 50-51
Sliding doors: see pages 42-43
